The purpose of a vapor barrier is straightforward: prevent ground vapor from rising into your crawl space or basement floor, where it can saturate wood framing, insulation, and HVAC equipment over time. Understanding what a proper vapor barrier consists of, however, goes well beyond simply laying plastic on the floor.
Standard 6-mil poly sheeting has a relatively high vapor permeance rating, meaning it allows some moisture vapor to pass through over time, particularly as it ages and develops micro-perforations from foot traffic and environmental factors. The material specification should match the specific moisture conditions and use patterns of the space, and we assess both before recommending a product.
Overlapping sheets by 12 inches or more at seams and securing them with butyl tape creates a continuous, mechanically bonded membrane that resists separation as the sheeting settles and moves over time. A perfectly spec'd 20-mil liner installed with poorly treated seams performs no better than a budget barrier at preventing moisture migration.
A properly installed vapor barrier extends up the wall from the floor, typically to the sill plate, and is secured with concrete adhesive or mechanical fasteners at the top. The combination of floor coverage, properly lapped and taped seams, and full wall coverage to the sill plate creates a complete moisture envelope that dramatically reduces crawl space humidity and protects the wood framing above.
The downstream benefits of a properly installed vapor barrier extend well beyond simply keeping the crawl space dry. A well-installed vapor barrier is also a prerequisite for effective dehumidifier integration in crawl spaces where mechanical moisture extraction is warranted.
Our installers are trained on manufacturer specifications for every product we use.
We source reinforced 20-mil poly sheeting and commercial butyl tape, not the hardware store equivalent.
Full perimeter coverage is non-negotiable in our installation standard.
Our vapor barrier installations carry a written warranty covering materials and workmanship.
We install reinforced polyethylene sheeting across the entire crawl space floor with full wall coverage and butyl-taped seams throughout.
Upgrading from 6-mil to 20-mil sheeting with proper seam sealing delivers measurably improved moisture performance in most cases.
The installation includes full seaming, perimeter taping, and wall coverage to the base of the finished wall or sill plate.
This combination approach addresses both vapor diffusion and water management in a single installation.
Full crawl space encapsulation combines a complete vapor barrier system with a dedicated dehumidifier sized for the space to achieve and maintain target humidity levels year-round.
Regular inspection of vapor barriers in Lansdowne crawl spaces is recommended every several years to catch deterioration before it leads to wood rot or mold conditions.
We measure the space, assess existing moisture conditions, document any existing barrier or mold, and identify all penetrations that will need to be addressed in the installation
Based on site conditions, we specify the appropriate mil rating, calculate material quantities, and plan the seaming layout for maximum coverage and minimum waste
Sheeting is laid, overlapped at 12 inches minimum, taped with butyl tape at all seams, and extended up all walls with mechanical fastening at the top edge
We walk through the completed installation with you, confirm all seams and coverages are complete, and provide written warranty documentation before leaving
"We had a previous vapor barrier installation that was barely 6-mil and had separated seams throughout. The humidity in our crawl space was unacceptable and we were starting to see mold on the floor joists. JCB Waterproofing and Construction came in, took out the failing old barrier, and installed a proper system that actually works. The difference in our indoor air quality was noticeable within a week."
"Very professional team that explained the difference between the grades of vapor barrier sheeting before recommending anything. The 20-mil they installed is rock solid and the seams are all properly taped. We can already see the humidity meter reading dropping consistently."
"The crew extended the barrier all the way up the walls to the sill plate, which the contractor who did our original installation did not do. The proper wall-to-sill installation finally completed our moisture protection. Great work from a team that clearly knows what they are doing."
Contact JCB Waterproofing and Construction for a free site evaluation and written estimate for vapor barrier installation in Lansdowne
